Working principle

The working principle of GF rotary drum filter is basically the same as that of general vacuum rotary drum filter. The main difference is that the GF filter is pre-coated with filter AIDS (such as diatomite, perlite, etc.) before filtration. During filtration, the filter aid in the tank body forms a pre-coating of the required thickness on the outer surface of the drum under the action of vacuum suction, and then infuses the slurry to be filtered. Under the action of vacuum suction, the separated filtrate passes through the pre-coating and filter cloth, and is discharged through the suction tube, liquid collector tube and gas-liquid separator. The solid particles in the slurry are trapped by the pre-coating and continuously scraped away by the automatic feed scraper along with the filter aid surface. When the residual thickness of the pre-coating is about 10mm, the pre-coating needs to be re-applied for the next working cycle.

Application

The product is mainly suitable for filtrate, do not filter slag occasions.

GF type pre-coated rotary drum vacuum filter application field.

1, all kinds of sugar liquid (glucose, maltose, dextrin, fruit extract, sucrose, etc.) filtration and deslag.

2, pharmaceutical industry taylormycin, macromycin and other fermentation liquid filtration and desludge.

3, amino acids, enzyme preparations and other fermentation liquid filtration deslag.

4, wine mud, rice wine mud filtration deslag.

5, food and beverage industry filtration and deslag.

6, chemical industry wastewater filtration and slag removal.

7. Pretreatment of membrane equipment before filtration.

8. Filtration of food additives such as carrageenan.

Product feature

1, customized design, should be different needs of customers.

2, the use of pre-coating technology, filtrate clarification is high.

3, automatic scraper discharge, high filtration efficiency.

4, the drum can be designed spray, material washing effect is good.

5, serialized process equipment, easy to install and use.

6, advanced and reasonable structure, beautiful and generous appearance.

7, excellent production environment, simple operation, convenient, labor-saving.

Main parameter
