What is a rotary filter?

A vacuum rotary filter is a solid-liquid separation device that utilizes vacuum suction to continuously perform filtering, washing, unloading, and other operations during the rotation of a cylinder. Here is a specific introduction:

Working principle: The outer wall of the drum has small holes and is wrapped with filter cloth. The interior is divided into several fan-shaped grids that are not connected to each other, and connected to the distribution head through the holes on the hollow shaft. The lower half of the drum is immersed in the filter slurry, while the upper half is exposed outside the tank. When the drum rotates, the fan-shaped grid passes through different areas in sequence. In the filtration zone, connected to vacuum, the filtrate passes through the filter cloth into the fan-shaped grid and is discharged; Next, in the drying area, continue to vacuum dry the remaining filtrate and filter cake; Then in the washing area, the washing water is sprayed onto the filter cake, and the washing water is sucked in and discharged; Finally, in the unloading area, it is connected to compressed air, and the filter cake is blown loose and peeled off by a scraper. After that, the filter cloth can be cleaned and enter the next cycle.

Product advantages

Rotating filters have outstanding advantages in the field of continuous solid-liquid separation. With the collaborative operation of vacuum negative pressure and rotating structure, this equipment not only achieves efficient and stable operation, but also forms differentiated competitiveness in space utilization, cost control and safety assurance, providing reliable technical solutions for industrial production.

High availability

Continuous availability ensures maximum filtering efficiency and uninterrupted production.

Small footprint

Compared to other filtration technologies of the same size, it occupies less ground space.

Good drying performance

Able to dry the filter cake and provide different unloading methods according to the type of product.

Pure filtrate

Pre coated drum filter can filter low solid content slurry and recover filtrate as pure and solid free as possible.

Low cost

It has the characteristics of low energy consumption and small maintenance, which can reduce capital expenditure and operating costs.

High safety

Fully enclosed design, can be equipped with protective covers to reduce the risk of dangerous product leakage, protect the safety of operators, and also protect vulnerable or non exposed products to be filtered.

Application fields

Rotary filters have demonstrated extensive application value in multiple industrial fields, with their core functions covering diverse scenarios from basic material processing to environmental governance.

Chemical and Mining: This equipment can efficiently separate industrial waste such as diatomaceous earth and activated carbon from cleaning water;

Food processing: for the solid-liquid separation needs of high-value materials such as yeast, protein, Rice noodles, starch, etc., its continuous operation characteristics can significantly improve the production efficiency;

Pharmaceutical industry: With its precise filtration capability, it effectively achieves reliable separation of drug solutions and impurities.

Environmental Protection Industry: Used for removing suspended solids in wastewater treatment, as well as controlling impurities in beverage production, and playing a key role in sludge dewatering treatment.

How do I know if a rotary filter is suitable for my process?

If your production process involves any of the following requirements, a rotary filter may provide you with an ideal solution.

Continuous solid-liquid separation: suitable for scenarios that require uninterrupted operation, capable of efficiently completing dynamic separation of solid-liquid mixtures;

Solid or liquid product recycling: Both solid materials and liquid products can be efficiently recycled;

Clarification of liquid products: for systems that require removal of suspended impurities or small particles, it can significantly improve product purity;

Filter cake washing: supports washing operations on the filter cake, which can improve the purity of the filter cake itself and further extract residual liquid products from it;

Wastewater purification treatment: It has efficient removal function for suspended solids, colloids and other pollutants in industrial wastewater, helping to achieve standard discharge or recycling of wastewater.

Yinuo Machinery After sales Service

The rotary filter produced by Yinuo Machinery has a complete after-sales service system. The specific after-sales service is as follows:

Technical services: Provide free comprehensive technical services before, during, and after sales, as well as other technical support;

Quality assurance service: The product quality is guaranteed according to the industry standard machine manual, with a one-year warranty period and a three guarantee service;

Supply of vulnerable parts: There is sufficient stock of equipment vulnerable parts, which can be shipped by express logistics according to customer needs at any time to ensure production needs.

FAQ

How to solve the problem of filter cloth clogging?

Due to the high number of solid particles in the filtrate, insufficient pre-treatment, or untimely cleaning of the filter cloth, or compatibility between the material pore size and the material department, screening and other pre-treatment steps can be added. The filter cloth should be regularly cleaned using high-pressure water chemical method, and the filter cloth should be selected according to the material characteristics.

How to deal with high moisture content in filter cake?

During work, there are often situations where the drum is immersed in the filtrate for a long time, the vacuum degree is insufficient, or the filter cake is not washed sufficiently. It can reduce the feeding speed, lower the immersion degree, improve the vacuum degree, or optimize the washing process.

How to solve the problem of poor slag discharge in equipment?

The reason is due to the small design of the slag discharge outlet, wear of the scraper, or excessive viscosity of the filter cake. The design of the slag discharge outlet can be improved, the scraper can be replaced, or the viscous material can be pre treated to reduce viscosity, which can ensure smooth slag discharge of the material.

Can high viscosity liquids be filtered?

This depends on the design and performance of the equipment. The rotating filter is specially designed to handle liquids of certain viscosity, but high viscosity liquids may affect filtration efficiency and may require pre-treatment measures such as preheating and dilution.
